Optical system:

Light source type: 371W OSRAM bulb

Light source life: 1500H

Prism: 5 rows of mirrors, 8 prisms (double prisms can be superimposed, can be rotated independently in both directions)

Color system: white light + 11 colors

Nebulizing Mirrors: Mild/Severe

Pattern system:

Fixed gobos: 1 white light (arbitrarily adjust the beam size) + 14 patterns, which can realize flowing water, jitter, random motion and slow rainbow effects in the positive and negative directions.

Dynamic effect gobo: white light + aperture + 3-segment arc dynamic effect + 3 patterns, which can realize flowing water, jitter, random motion and slow rainbow effect in the front and back directions.

Metal rotating gobos: white light + 7 glass patterns, which can achieve flowing water, jitter, random motion and slow rainbow effects in the forward and reverse directions.

Rotating gobos: 12 rotatable patterns + white light, variable speed jitter and bidirectional flow effect

Swivel: 540° (16 bit)

Vertical rotation: 270° (16 bit)

IP rating: IP20

Focusing: Using a combination of 3 sets of optical lenses, the effect is far better than that of ordinary beam lights, and it can project high-definition patterns

Opening angle: 3-50 degrees linear adjustment, the maximum opening angle is 60 degrees

Strobe: pulse strobe, synchronous asynchronous strobe, 0~20Hz

Dimming: 0~100% linear dimming

DMX512, RDM, Artnet (optional),

Four operating modes (DMX mode, auto-propelled mode, voice-activated mode, and scene mode)

LCD 16 million color touch TFT interface, easy to operate, beautiful interface, the interface can be reversed 180 degrees.

Control channel: 19CH/23CH

Input voltage: AC100-240V, 50/60 Hz
