Technical parameters

Voltage: AC100V-240V, 50/60Hz.

Rated power: 550W.

Light source: 1 high-brightness and high-power 400W white LED module.

Light source color temperature: 7800K.

Color Wheel 1: 6 colors + white light, rainbow effect can be rotated in both directions.

Color Wheel 2: 8 colors + white light, rainbow effect can be rotated in both directions.

CT0: 2800K-6500K can be adjusted linearly.

Gobos: 7 gobos + white circles.

Cutting Disc: A set of 4 chamfering blades that can be controlled by the spot chamfering system, through the precise control of the cutting blade, can create any shape of the light spot.

Beam angle: 4°-40°, variable zoom lens, linear magnification and reduction function.

Control channels: 26 channels.

Operating mode: voice-activated, auto-propelled, master-slave, DMX512, Art-NET, RDM.

Focusing: DMX linear high-definition focusing, the definition of the pattern can be adjusted freely.

Atomization: The built-in atomization mirror can generate a softening effect adjustment, 0%~100% linear atomization.

Strobe: 1-25 times/second ultra-high-speed strobe effect, random strobe and pulse strobe can be selected.

Dimming: 0-100% linear dimming.

Aperture: 5%~100% smooth adjustment.

Color rendering index: Ra≥90.

Horizontal/Vertical: Horizontal 540°, Vertical 270°, 16Bit precision scanning, automatic return correction function.

System: RDM control box upgrade software.

Intelligent RMD motherboard remote address code, saving time and labor.

Heat dissipation: Lamp bead copper tube heat dissipation, axial flow fan in and out of two-way heat exhaust cooling.

Display: The display panel adopts a 2.8-inch resistive color touch screen, with physical buttons, good press sensitivity, Chinese and English display, and can be intelligently reversed display.

Intelligent temperature control: Magnetic levitation intelligent controllable speed fan, better heat dissipation and quieter. The built-in temperature protection sensor can automatically adjust the power of the lamp for over-temperature protection, and the display panel can check the working temperature of the lamp in real time.

Lamp shell: high-temperature resistant engineering flame retardant plastic and alloy materials, self-extinguishing from open flame, streamlined design, beautiful and generous appearance.

Net weight: 24KGS

Dimensions: L390×W280×H670mm

Packing size: L750×W360×H470mm
