1. Technical Parameters

Voltage: AC100V-240V, 50/60Hz.

Light source: 1 high-brightness and high-power LED400W, 500W, 600W white LED module.

Light source color temperature: 7800K.

Color wheel: 8 colors + white light + CTO, rainbow effect can be rotated in both directions.

CMY mixing: cyan, magenta, yellow, uniform and smooth infinitely mixed color.

2 gobos, fixed gobos: 12 fixed gobos + white circles with pattern jitter function, rotating gobos: 7 rotating gobos + white circles.

Beam angle: 4°-40°, variable zoom lens, linear magnification and reduction function.

Control Channels: 2 Channel Modes: 25/30 International Standard DMX512 Channels.

Operating mode: voice-activated, auto-propelled, master-slave, DMX512, Art-NET, RDM.

Prism: 2 prism disks, 1 8 prisms, 1 6 rows of mirrors, the prism can rotate in both directions, the rotation speed is adjustable, and the prism can be superimposed into a composite effect.

Focusing: DMX linear high-definition focusing, the definition of the pattern can be adjusted freely.

Atomization: The built-in atomization mirror can generate a softening effect adjustment, 0%~100% linear atomization.

Strobe: 1-25 times/second ultra-high-speed strobe effect, random strobe and pulse strobe can be selected.

Dimming: 0-100% linear dimming.

Aperture: 5%~100% smooth adjustment.

Color rendering index: Ra≥90.

Horizontal/Vertical: Horizontal 540°, Vertical 270°, 16Bit precision scanning, automatic return correction function.

Lamp shell: high-temperature resistant engineering flame retardant plastic and alloy materials, self-extinguishing from open flame, streamlined design, beautiful and generous appearance.

System: RDM control box upgrade software.

Heat dissipation: Lamp bead copper tube heat dissipation, axial flow fan in and out of two-way heat exhaust cooling.

Display: The display panel adopts a 2.8-inch resistive color touch screen, with physical buttons, good press sensitivity, Chinese and English display, and can be intelligently reversed display.

Intelligent temperature control: Magnetic levitation intelligent controllable speed fan, better heat dissipation and quieter. The built-in temperature protection sensor can automatically adjust the power of the lamp for over-temperature protection, and the display panel can check the working temperature of the lamp in real time.

Lamp shell: high-temperature resistant engineering flame retardant plastic and alloy materials, self-extinguishing from open flame, streamlined design, beautiful and generous appearance.

Net weight: 23KGS

Dimensions: L370×W280×H660mm

Packing size: L770×W380×H490mm
